John Deere

620 All Fuel Row Crop (1956-1958)

add yours to registry

add/remove from wishlist - view your list

add tractor information

Tractor Info

1956-1958

The 620 tractor was the direct replacement to the model 60 tractor. It offered close to the same horsepower of the John Deere 70 at a very close price comparrision. Advertised as a four bottom plow tractor, it could take on the dual task of a field workhorse and barn lot tractor. With the various chassis configurations it made the model 620 one of the most diverse tractors in the barn.


Tractor Info

Engine: John Deere

Cylinders: 2

Bore & Stroke: 5.50 x 6.38

RPM: 1125

CID: 303

Fuel: Distillate

Main Fuel Tank Cap: 20 GAL.

Aux Fuel Tank Cap: 1 Gallon

Carburetor: Marvel Schebler

Cooling Capacity: 26 QTS.

Drawbar HP: 32.37

Belt PTO HP: 34.57

Weight: up to 6800 lbs

Length: 135.25 inches

Width: 86.25 inches

Height: 88.125 inches

Number of Gears: 6/1

Options:


Total Produced: 474
