J.I. Case

1175 (1971-1978)

add yours to registry

add/remove from wishlist - view your list

add tractor information

Tractor Info


This was the follow up tractor to the Case 1170. The 1175 had the same power level as the 1170 but included a roll-protective frame. A sound-proof and air-conditioned cab came as an additional option for the 1175. These cabs helped to improve the operators environment and reduces fatigue.

Tractor Info

Engine: Case Turbo

Cylinders: 6

Bore & Stroke: 4.375 x 5.00

RPM: 2100

CID: 451

Fuel: Diesel

Main Fuel Tank Cap:

Aux Fuel Tank Cap:


Cooling Capacity:

Drawbar HP:

PTO HP: 121.9

Weight: 12,180 lbs

Length: inches

Width: inches

Height: inches

Number of Gears: 8/2


Total Produced: 8,372

1971: 8674001

1972: 8693001

1973: 8712001

1974: 8736601

1975: 8770001

1976: 8797501

1977: 8810601

1978: 8830001

Location: On the left side above the platform floor, next to the steering wheel
